ioftools / networkxMiCe / networkxmaster / networkx / algorithms / operators / product.py @ 5cef0f13
History  View  Annotate  Download (13.9 KB)
1
# Copyright (C) 2011 by


2
# Aric Hagberg <hagberg@lanl.gov>

3
# Dan Schult <dschult@colgate.edu>

4
# Pieter Swart <swart@lanl.gov>

5
# All rights reserved.

6
# BSD license.

7
#

8
# Authors:

9
# Aric Hagberg <hagberg@lanl.gov>

10
# Pieter Swart <swart@lanl.gov>

11
# Dan Schult <dschult@colgate.edu>

12
# Ben Edwards <bedwards@cs.unm.edu>

13
"""

14
Graph products.

15
"""

16
from itertools import product
17
18
import networkx as nx
19
from networkx.utils import not_implemented_for
20
21
__all__ = ['tensor_product', 'cartesian_product',
22
'lexicographic_product', 'strong_product', 'power',
23
'rooted_product']

24
25
26
def _dict_product(d1, d2):
27
return dict((k, (d1.get(k), d2.get(k))) for k in set(d1)  set(d2))
28
29
30
# Generators for producting graph products

31
def _node_product(G, H):
32
for u, v in product(G, H):
33
yield ((u, v), _dict_product(G.nodes[u], H.nodes[v]))

34
35
36
def _directed_edges_cross_edges(G, H):
37
if not G.is_multigraph() and not H.is_multigraph():
38
for u, v, c in G.edges(data=True):
39
for x, y, d in H.edges(data=True):
40
yield (u, x), (v, y), _dict_product(c, d)

41
if not G.is_multigraph() and H.is_multigraph():
42
for u, v, c in G.edges(data=True):
43
for x, y, k, d in H.edges(data=True, keys=True):
44
yield (u, x), (v, y), k, _dict_product(c, d)

45
if G.is_multigraph() and not H.is_multigraph():
46
for u, v, k, c in G.edges(data=True, keys=True):
47
for x, y, d in H.edges(data=True):
48
yield (u, x), (v, y), k, _dict_product(c, d)

49
if G.is_multigraph() and H.is_multigraph():
50
for u, v, j, c in G.edges(data=True, keys=True):
51
for x, y, k, d in H.edges(data=True, keys=True):
52
yield (u, x), (v, y), (j, k), _dict_product(c, d)

53
54
55
def _undirected_edges_cross_edges(G, H):
56
if not G.is_multigraph() and not H.is_multigraph():
57
for u, v, c in G.edges(data=True):
58
for x, y, d in H.edges(data=True):
59
yield (v, x), (u, y), _dict_product(c, d)

60
if not G.is_multigraph() and H.is_multigraph():
61
for u, v, c in G.edges(data=True):
62
for x, y, k, d in H.edges(data=True, keys=True):
63
yield (v, x), (u, y), k, _dict_product(c, d)

64
if G.is_multigraph() and not H.is_multigraph():
65
for u, v, k, c in G.edges(data=True, keys=True):
66
for x, y, d in H.edges(data=True):
67
yield (v, x), (u, y), k, _dict_product(c, d)

68
if G.is_multigraph() and H.is_multigraph():
69
for u, v, j, c in G.edges(data=True, keys=True):
70
for x, y, k, d in H.edges(data=True, keys=True):
71
yield (v, x), (u, y), (j, k), _dict_product(c, d)

72
73
74
def _edges_cross_nodes(G, H):
75
if G.is_multigraph():

76
for u, v, k, d in G.edges(data=True, keys=True):
77
for x in H:
78
yield (u, x), (v, x), k, d

79
else:

80
for u, v, d in G.edges(data=True):
81
for x in H:
82
if H.is_multigraph():

83
yield (u, x), (v, x), None, d
84
else:

85
yield (u, x), (v, x), d

86
87
88
def _nodes_cross_edges(G, H):
89
if H.is_multigraph():

90
for x in G:
91
for u, v, k, d in H.edges(data=True, keys=True):
92
yield (x, u), (x, v), k, d

93
else:

94
for x in G:
95
for u, v, d in H.edges(data=True):
96
if G.is_multigraph():

97
yield (x, u), (x, v), None, d
98
else:

99
yield (x, u), (x, v), d

100
101
102
def _edges_cross_nodes_and_nodes(G, H):
103
if G.is_multigraph():

104
for u, v, k, d in G.edges(data=True, keys=True):
105
for x in H:
106
for y in H:
107
yield (u, x), (v, y), k, d

108
else:

109
for u, v, d in G.edges(data=True):
110
for x in H:
111
for y in H:
112
if H.is_multigraph():

113
yield (u, x), (v, y), None, d
114
else:

115
yield (u, x), (v, y), d

116
117
118
def _init_product_graph(G, H):
119
if not G.is_directed() == H.is_directed():
120
msg = "G and H must be both directed or both undirected"

121
raise nx.NetworkXError(msg)

122
if G.is_multigraph() or H.is_multigraph():
123
GH = nx.MultiGraph()
124
else:

125
GH = nx.Graph()
126
if G.is_directed():

127
GH = GH.to_directed()
128
return GH

129
130
131
def tensor_product(G, H):
132
r"""Returns the tensor product of G and H.

133

134
The tensor product $P$ of the graphs $G$ and $H$ has a node set that

135
is the tensor product of the node sets, $V(P)=V(G) \times V(H)$.

136
$P$ has an edge $((u,v), (x,y))$ if and only if $(u,x)$ is an edge in $G$

137
and $(v,y)$ is an edge in $H$.

138

139
Tensor product is sometimes also referred to as the categorical product,

140
direct product, cardinal product or conjunction.

141

142

143
Parameters

144


145
G, H: graphs

146
Networkx graphs.

147

148
Returns

149


150
P: NetworkX graph

151
The tensor product of G and H. P will be a multigraph if either G

152
or H is a multigraph, will be a directed if G and H are directed,

153
and undirected if G and H are undirected.

154

155
Raises

156


157
NetworkXError

158
If G and H are not both directed or both undirected.

159

160
Notes

161


162
Node attributes in P are twotuple of the G and H node attributes.

163
Missing attributes are assigned None.

164

165
Examples

166


167
>>> G = nx.Graph()

168
>>> H = nx.Graph()

169
>>> G.add_node(0, a1=True)

170
>>> H.add_node('a', a2='Spam')

171
>>> P = nx.tensor_product(G, H)

172
>>> list(P)

173
[(0, 'a')]

174

175
Edge attributes and edge keys (for multigraphs) are also copied to the

176
new product graph

177
"""

178
GH = _init_product_graph(G, H)
179
GH.add_nodes_from(_node_product(G, H))
180
GH.add_edges_from(_directed_edges_cross_edges(G, H))
181
if not GH.is_directed():
182
GH.add_edges_from(_undirected_edges_cross_edges(G, H))
183
return GH

184
185
186
def cartesian_product(G, H):
187
r"""Returns the Cartesian product of G and H.

188

189
The Cartesian product $P$ of the graphs $G$ and $H$ has a node set that

190
is the Cartesian product of the node sets, $V(P)=V(G) \times V(H)$.

191
$P$ has an edge $((u,v),(x,y))$ if and only if either $u$ is equal to $x$

192
and both $v$ and $y$ are adjacent in $H$ or if $v$ is equal to $y$ and

193
both $u$ and $x$ are adjacent in $G$.

194

195
Parameters

196


197
G, H: graphs

198
Networkx graphs.

199

200
Returns

201


202
P: NetworkX graph

203
The Cartesian product of G and H. P will be a multigraph if either G

204
or H is a multigraph. Will be a directed if G and H are directed,

205
and undirected if G and H are undirected.

206

207
Raises

208


209
NetworkXError

210
If G and H are not both directed or both undirected.

211

212
Notes

213


214
Node attributes in P are twotuple of the G and H node attributes.

215
Missing attributes are assigned None.

216

217
Examples

218


219
>>> G = nx.Graph()

220
>>> H = nx.Graph()

221
>>> G.add_node(0, a1=True)

222
>>> H.add_node('a', a2='Spam')

223
>>> P = nx.cartesian_product(G, H)

224
>>> list(P)

225
[(0, 'a')]

226

227
Edge attributes and edge keys (for multigraphs) are also copied to the

228
new product graph

229
"""

230
GH = _init_product_graph(G, H)
231
GH.add_nodes_from(_node_product(G, H))
232
GH.add_edges_from(_edges_cross_nodes(G, H))
233
GH.add_edges_from(_nodes_cross_edges(G, H))
234
return GH

235
236
237
def lexicographic_product(G, H):
238
r"""Returns the lexicographic product of G and H.

239

240
The lexicographical product $P$ of the graphs $G$ and $H$ has a node set

241
that is the Cartesian product of the node sets, $V(P)=V(G) \times V(H)$.

242
$P$ has an edge $((u,v), (x,y))$ if and only if $(u,v)$ is an edge in $G$

243
or $u==v$ and $(x,y)$ is an edge in $H$.

244

245
Parameters

246


247
G, H: graphs

248
Networkx graphs.

249

250
Returns

251


252
P: NetworkX graph

253
The Cartesian product of G and H. P will be a multigraph if either G

254
or H is a multigraph. Will be a directed if G and H are directed,

255
and undirected if G and H are undirected.

256

257
Raises

258


259
NetworkXError

260
If G and H are not both directed or both undirected.

261

262
Notes

263


264
Node attributes in P are twotuple of the G and H node attributes.

265
Missing attributes are assigned None.

266

267
Examples

268


269
>>> G = nx.Graph()

270
>>> H = nx.Graph()

271
>>> G.add_node(0, a1=True)

272
>>> H.add_node('a', a2='Spam')

273
>>> P = nx.lexicographic_product(G, H)

274
>>> list(P)

275
[(0, 'a')]

276

277
Edge attributes and edge keys (for multigraphs) are also copied to the

278
new product graph

279
"""

280
GH = _init_product_graph(G, H)
281
GH.add_nodes_from(_node_product(G, H))
282
# Edges in G regardless of H designation

283
GH.add_edges_from(_edges_cross_nodes_and_nodes(G, H))
284
# For each x in G, only if there is an edge in H

285
GH.add_edges_from(_nodes_cross_edges(G, H))
286
return GH

287
288
289
def strong_product(G, H):
290
r"""Returns the strong product of G and H.

291

292
The strong product $P$ of the graphs $G$ and $H$ has a node set that

293
is the Cartesian product of the node sets, $V(P)=V(G) \times V(H)$.

294
$P$ has an edge $((u,v), (x,y))$ if and only if

295
$u==v$ and $(x,y)$ is an edge in $H$, or

296
$x==y$ and $(u,v)$ is an edge in $G$, or

297
$(u,v)$ is an edge in $G$ and $(x,y)$ is an edge in $H$.

298

299
Parameters

300


301
G, H: graphs

302
Networkx graphs.

303

304
Returns

305


306
P: NetworkX graph

307
The Cartesian product of G and H. P will be a multigraph if either G

308
or H is a multigraph. Will be a directed if G and H are directed,

309
and undirected if G and H are undirected.

310

311
Raises

312


313
NetworkXError

314
If G and H are not both directed or both undirected.

315

316
Notes

317


318
Node attributes in P are twotuple of the G and H node attributes.

319
Missing attributes are assigned None.

320

321
Examples

322


323
>>> G = nx.Graph()

324
>>> H = nx.Graph()

325
>>> G.add_node(0, a1=True)

326
>>> H.add_node('a', a2='Spam')

327
>>> P = nx.strong_product(G, H)

328
>>> list(P)

329
[(0, 'a')]

330

331
Edge attributes and edge keys (for multigraphs) are also copied to the

332
new product graph

333
"""

334
GH = _init_product_graph(G, H)
335
GH.add_nodes_from(_node_product(G, H))
336
GH.add_edges_from(_nodes_cross_edges(G, H))
337
GH.add_edges_from(_edges_cross_nodes(G, H))
338
GH.add_edges_from(_directed_edges_cross_edges(G, H))
339
if not GH.is_directed():
340
GH.add_edges_from(_undirected_edges_cross_edges(G, H))
341
return GH

342
343
344
@not_implemented_for('directed')
345
@not_implemented_for('multigraph')
346
def power(G, k):
347
"""Returns the specified power of a graph.

348

349
The $k$th power of a simple graph $G$, denoted $G^k$, is a

350
graph on the same set of nodes in which two distinct nodes $u$ and

351
$v$ are adjacent in $G^k$ if and only if the shortest path

352
distance between $u$ and $v$ in $G$ is at most $k$.

353

354
Parameters

355


356
G : graph

357
A NetworkX simple graph object.

358

359
k : positive integer

360
The power to which to raise the graph `G`.

361

362
Returns

363


364
NetworkX simple graph

365
`G` to the power `k`.

366

367
Raises

368


369
ValueError

370
If the exponent `k` is not positive.

371

372
NetworkXNotImplemented

373
If `G` is not a simple graph.

374

375
Examples

376


377
The number of edges will never decrease when taking successive

378
powers:

379

380
>>> G = nx.path_graph(4)

381
>>> list(nx.power(G, 2).edges)

382
[(0, 1), (0, 2), (1, 2), (1, 3), (2, 3)]

383
>>> list(nx.power(G, 3).edges)

384
[(0, 1), (0, 2), (0, 3), (1, 2), (1, 3), (2, 3)]

385

386
The `k`th power of a cycle graph on *n* nodes is the complete graph

387
on *n* nodes, if `k` is at least ``n // 2``:

388

389
>>> G = nx.cycle_graph(5)

390
>>> H = nx.complete_graph(5)

391
>>> nx.is_isomorphic(nx.power(G, 2), H)

392
True

393
>>> G = nx.cycle_graph(8)

394
>>> H = nx.complete_graph(8)

395
>>> nx.is_isomorphic(nx.power(G, 4), H)

396
True

397

398
References

399


400
.. [1] J. A. Bondy, U. S. R. Murty, *Graph Theory*. Springer, 2008.

401

402
Notes

403


404
This definition of "power graph" comes from Exercise 3.1.6 of

405
*Graph Theory* by Bondy and Murty [1]_.

406

407
"""

408
if k <= 0:
409
raise ValueError('k must be a positive integer')
410
H = nx.Graph()
411
H.add_nodes_from(G)
412
# update BFS code to ignore self loops.

413
for n in G:
414
seen = {} # level (number of hops) when seen in BFS

415
level = 1 # the current level
416
nextlevel = G[n]
417
while nextlevel:

418
thislevel = nextlevel # advance to next level

419
nextlevel = {} # and start a new list (fringe)

420
for v in thislevel:
421
if v == n: # avoid self loop
422
continue

423
if v not in seen:
424
seen[v] = level # set the level of vertex v

425
nextlevel.update(G[v]) # add neighbors of v

426
if k <= level:

427
break

428
level += 1

429
H.add_edges_from((n, nbr) for nbr in seen)
430
return H

431
432
433
@not_implemented_for('multigraph')
434
def rooted_product(G, H, root):
435
""" Return the rooted product of graphs G and H rooted at root in H.

436

437
A new graph is constructed representing the rooted product of

438
the inputted graphs, G and H, with a root in H.

439
A rooted product duplicates H for each nodes in G with the root

440
of H corresponding to the node in G. Nodes are renamed as the direct

441
product of G and H. The result is a subgraph of the cartesian product.

442

443
Parameters

444


445
G,H : graph

446
A NetworkX graph

447
root : node

448
A node in H

449

450
Returns

451


452
R : The rooted product of G and H with a specified root in H

453

454
Notes

455


456
The nodes of R are the Cartesian Product of the nodes of G and H.

457
The nodes of G and H are not relabeled.

458
"""

459
if root not in H:
460
raise nx.NetworkXError('root must be a vertex in H')
461
462
R = nx.Graph()
463
R.add_nodes_from(product(G, H))
464
465
R.add_edges_from(((e[0], root), (e[1], root)) for e in G.edges())
466
R.add_edges_from(((g, e[0]), (g, e[1])) for g in G for e in H.edges())
467
468
return R
