What’s So Special About 32?

It has to do with the way computers think and the way Microsoft tried to organize things.

I had to chuckle when I read this question. It’s a perfect example of how things computer folks take for granted are just so much magic to “real” people.

32 is special because it comes after 16 and before 64. (Which I’m sure doesn’t help at all.)

The transition from 8 to 16 to 32 and beyond

Computers use bits valued at either “1” or “0” to represent all data. For convenience, bits are grouped into eight-bit bytes. Early personal computers processed data one byte at a time, and thus were referred to as eight-bit computers. As technology advanced, computers evolved to process 16 bits, then 32, and now 64 bits at a time. Software and operating systems like Windows had to adapt to these changes. One result of that adaptation is folder and file naming conventions, which in Windows can be quite confusing due to the evolution of the transition.

In the beginning was the bit

To refresh, modern digital computers really only know two things: “1” or “0”.

Or put another way, they can know only single things, called bits, that can be either on or off, zero or one.

Seriously, that’s all they know. Every computer program, every digital photo, every music file, every video you watch, even the text you’re looking at right now is nothing more than a collection of bits. A lot of bits, but only bits … 1’s and 0’s. This is the definition of digital.1

I’ve often joked that my job is nothing more than putting a lot of zeros and ones in the right order.

Groups of bits

It’s cumbersome to have to think of everything as a series of 1’s and 0’s, so there are some convenient ways of grouping them.

You’ve probably already heard of a byte, which is a collection of eight bits. If you look at the number of possible different combinations of how those eight bits can be set — each on or off — you’ll find that there are 256 possible combinations: 00000000 through 11111111, or, more conveniently, 0 through 255. You’ll also sometimes see them represented in hexadecimal notation, like 00 through FF — a topic for another day.

The first popular microprocessors used in personal computers back in the days of the Apple II and the Altair dealt with data one byte at a time. Thus they were called eight-bit computers.

Bits and microprocessors

When the IBM PC was introduced, it used a processor that was effectively a 16-bit processor2, handling data 16 bits, or two bytes, at a time.

Over the years, processors evolved to handle information four bytes at a time and thus were called 32-bit computers. Most modern machines now use 64-bit processors capable of handling data eight bytes at a time.

In case you couldn’t guess from the progression — 8, then 16, 32, and 64 — processors tend to double the way they look at data as the technology improves. Is a 128-bit processor on the horizon? They exist, but whether or not they’ll become mainstream is unclear.

Bits and software

As the Intel-based processors used in the IBM and compatible machines grew in power and made those leaps from 8 to 16 and so on, software became an issue.

In general, software written to run on a 16-bit processor would not run on a 32-bit machine, at least not without help. That help comes in the form of compatibility modes on the 32-bit processors that allow them to “act like” 16-bit processors. Similarly, 32-bit software wouldn’t run on 64-bit processors without help.

In reality, the cart led the horse. MS-DOS and early versions of Windows were, in fact, 16-bit software, so even 32-bit processors were running in compatibility mode most of the time. Slowly, as 32-bit versions of Windows and other software were written to replace older code, the processor’s new features, like true multitasking, proper virtual memory, and lots of physical memory, could be exploited. A similar progression happened during the transition from 32- to 64-bit software.

Bits and Windows

Windows and other operating systems had the ability to provide that help but needed to keep things organized.

64-bit software needed the operating system to provide 64-bit support, 32-bit software needed 32-bit support, while 16-bit software needed the operating system to handle 16-bit specific support. 3

Thus things like SYSTEM32 were born. It was the directory to hold the 32-bit versions of Windows components. The old SYSTEM directory was left to hold the older 16-bit versions. Internally and among programmers, though, there were many references to win32, win16, and now win64.

When you see the “32” in an actual file name, it’s often the result of the same evolution. That’s probably the 32-bit version of a program or component.

So where’s System64?

Ugh. This is where things get more confusing.

In 64-bit versions of Windows — meaning all current versions — the folder we might expect to be “System64” is called … wait for it … “System32”. Specifically, in Windows 64-bit systems:

• The folder for 64-bit system software is C:\Windows\System32.
• The folder for 32-bit system software that runs in 64-bit Windows is C:\Windows\SysWOW64.

“WOW” stands for “Windows On Windows”, or more completely “running Windows 32 on Windows 64”. (In the past, it also meant Windows 16 on Windows 32, and so on.)

Either way, it’s confusing, but it is what it is.

Rules are meant to be bent

What I’ve outlined so far is the ideal, the theory, or the standard layout of files.

More or less.

It’s best thought of as a rule of thumb rather than absolute laws all programmers follow. As we’ve progressed from 16 to 32 to 64, these rules haven’t always been followed exactly, and they don’t apply in all cases. But they do apply in most.

The concepts, at least, remain the same. It’s all about organizing the software according to the “bit-ness” (16, 32, or 64) required to run it properly.
